Description
CT 320-P® – The machine operates independently of the power grid. No generator is required for outdoor use. Designed for the toughest applications and soils. Reinforced ball bearings ensure smooth and quiet operation of the milling machine. The continuously variable drive is standard equipment.
Ergonomically cushioned handles ensure fatigue-free operation of the CT 320-P®. Tremendous aggressiveness when removing concrete, asphalt, coatings, and road markings. Scraper blades or diamond tools for easy removal of flexible plastic coatings and epoxy resins. Specially manufactured diamond tools for slatted floors and walkways to increase slip resistance. Variable cutting width for joint repairs and/or full width for distance milling (shaving).
Integrated suction connection – protect yourself and your employees. Work cleanly, environmentally consciously, and with low dust levels using the appropriate extraction system.
|
Machine type |
CT 320-P® hand-guided demarcation milling machine |
|
Motor power |
35 hp, gasoline |
|
engine speed |
3600 min-1 |
|
Motor power (feed motor) |
0.17 kW |
|
Motor rated current (feed motor) |
1.2 A |
|
Motor speed (feed motor) |
3000 min-1 |
|
Working width |
320/340 Diamond Drum mm |
|
Tool speed / stroke |
1571 min-1 |
|
extraction system |
TORNADO/R2D2 |
|
Hose connection diameter |
70/125 mm |
|
Weight |
approx. 267 kg |
|
Dimensions, LxWxH (without equipment) |
approx.1,10 m x 0,66 m x 1,18 m |
Technical changes and errors excepted
Specifications refer to standard equipment, modifications on request
illustrations similar resp. partly including special accessories.
